The three-layers edge glued panel is made up of very high quality full staves, glued and crossed to three layers.
This structure gives the panel a high mechanical strength that makes it ideal for use in the manufacture of furniture, stairs, coverings, window frames.
3-layers of 7 mm panel
Middle panel with grain perpendicular to the outside ones
Formaldehyde contents according to E1 regulation
BOTANICAL NAME
Fagus sylvatica L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Weaving: very fine
Grain: not always straight
Average Specific Weight: 730 kg/m3
Withdrawal: high
Nervousness: High
Hardness: high
Axial Compression resistance: mean Value 61 MPa
Bending strength: mean Value 118 MPa
Modulus of elasticity: mean Value 14.700 MPa
Impact Resistance: High
Flexibility: medium
Durability: Mediocre
BOTANICAL NOME
Quercus spp.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average weight: 720-800 kg/m3
Shrinkage: Medium to high
Dimensional stability: Strong
Hardness: Medium to high
Compression strength: Average value 52-61 MPa
Flexural strength: Average value 106-108 MPa
Modulus of elasticity: Average value 12,500 MPa
Shock resistance: Good
Flexibility: Fair
Durability: Good
BOTANICAL NAME
Fraxinus excelsior L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average Specific Weight: 720 kg/m3
Shrinkage: Medium
Dimensional stability: Medium
Hardness: Medium
Compression strength: Average value: 51 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: mean Value 12.800 MPa
Shock resistance: Significant
Flexibility: Fair
Durability: Low to average
BOTANICAL NAME
Fagus sylvatica L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Weaving: very fine
Grain: not always straight
Average Specific Weight: 730 kg/m3
Withdrawal: high
Nervousness: High
Hardness: high
Axial Compression resistance: mean Value 61 MPa
Bending strength: mean Value 118 MPa
Modulus of elasticity: mean Value 14.700 MPa
Impact Resistance: High
Flexibility: medium
Durability: Mediocre
BOTANICAL NAME
Fagus sylvatica L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Weaving: very fine
Grain: not always straight
Average Specific Weight: 730 kg/m3
Withdrawal: high
Nervousness: High
Hardness: high
Axial Compression resistance: mean Value 61 MPa
Bending strength: mean Value 118 MPa
Modulus of elasticity: mean Value 14.700 MPa
Impact Resistance: High
Flexibility: medium
Durability: Mediocre
BOTANICAL NOME
Quercus spp.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average weight: 720-800 kg/m3
Shrinkage: Medium to high
Dimensional stability: Strong
Hardness: Medium to high
Compression strength: Average value 52-61 MPa
Flexural strength: Average value 106-108 MPa
Modulus of elasticity: Average value 12,500 MPa
Shock resistance: Good
Flexibility: Fair
Durability: Good
BOTANICAL NAME
Fraxinus excelsior L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average Specific Weight: 720 kg/m3
Shrinkage: Medium
Dimensional stability: Medium
Hardness: Medium
Compression strength: Average value: 51 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: mean Value 12.800 MPa
Shock resistance: Significant
Flexibility: Fair
Durability: Low to average
BOTANICAL NOME
Quercus spp.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average weight: 720-800 kg/m3
Shrinkage: Medium to high
Dimensional stability: Strong
Hardness: Medium to high
Compression strength: Average value 52-61 MPa
Flexural strength: Average value 106-108 MPa
Modulus of elasticity: Average value 12,500 MPa
Shock resistance: Good
Flexibility: Fair
Durability: Good
BOTANICAL NAME
Fagus sylvatica L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Weaving: very fine
Grain: not always straight
Average Specific Weight: 730 kg/m3
Withdrawal: high
Nervousness: High
Hardness: high
Axial Compression resistance: mean Value 61 MPa
Bending strength: mean Value 118 MPa
Modulus of elasticity: mean Value 14.700 MPa
Impact Resistance: High
Flexibility: medium
Durability: Mediocre
BOTANICAL NOME
Quercus spp.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average weight: 720-800 kg/m3
Shrinkage: Medium to high
Dimensional stability: Strong
Hardness: Medium to high
Compression strength: Average value 52-61 MPa
Flexural strength: Average value 106-108 MPa
Modulus of elasticity: Average value 12,500 MPa
Shock resistance: Good
Flexibility: Fair
Durability: Good
BOTANICAL NAME
Fraxinus excelsior L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average Specific Weight: 720 kg/m3
Shrinkage: Medium
Dimensional stability: Medium
Hardness: Medium
Compression strength: Average value: 51 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: mean Value 12.800 MPa
Shock resistance: Significant
Flexibility: Fair
Durability: Low to average
BOTANICAL NAME
Fraxinus excelsior L.
PHYSICAL AND MECHANICAL CHARACTERISTICS
Texture: Gross
Grain: Fairly straight and regular
Average Specific Weight: 720 kg/m3
Shrinkage: Medium
Dimensional stability: Medium
Hardness: Medium
Compression strength: Average value: 51 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: mean Value 12.800 MPa
Shock resistance: Significant
Flexibility: Fair
Durability: Low to average
