Solid Edge-glued Panel

Product Description


The Solid Edge-glued Panel is made of excellent quality wood by gluing whole lamellas with fixed or variable width, carefully selected and chosen to give uniformity of colouring.
The whole list panel is particularly elegant and suitable for the production of furniture and ladders.

Technical Informations

Size


– Thickness: mm 20-27-32-40-45
– Length: up to 3000 mm
– Width: max mm 1250
– Stave: Random 50 – 100 mm

Technological characteristics


– Solid whole staves
– Glueing: UNI EN 204 D3
– Humidity: 8% +/-2
– Formaldehyde content according to standard E1

Wood species available

Botanical name rovere europeo:
Quercus petraea L.

Local names: Roul, Galera, Gettina, Ischia

Names in other European countries: French: Rouvre, Chêne pedunculé; English (generic): Oak; Italian: Rovere europeo; German: Stieleiche, Traubeneiche; Spanish: Roble.

Origin: Origin In ancient times the common oak dominated the Po Valley in Italy but now occupies a much-reduced area. In Central and Southern Italy, the other two species are dominant. In Central and Eastern Europe, the common oak forms extensive top-quality forests.


The yellowish-white sapwood is sharply differentiated from the brown heartwood that changes to darker shades over time. The medullary rays are very obvious, especially on radial surfaces where shiny areas form. Thanks to the large pores of the spring wood, growth rings are clearly identifiable. The fresh-cut wood has a strong acid smell and blackish spots appear on it from contact with metal tools.

The drying process is slow and not very easy because it is difficult to obtain a uniform distribution of moisture through the boards, especially if they are thick. Faced with this difficulty, if use is made of hot-air ovens, collapse and localized warping are often seen.

Texture: Coarse
Grain: Fairly straight and regular
Average Specific Weight: 720 kg/m3
Withdrawal: high
Nervousness: High
Hardness: Medium to high
Axial Compression resistance: mean Value 61 MPa
Flexural strength: Average value: 108 MPa
Modulus of elasticity: Average value: 12,500 MPa
Impact Resistance: High
Flexibility: medium
Durability: Good for heartwood

Botanical name American White Oak:
Quercus alba

Local names: White Oak

Names in other European countries: English (generic): Oak; Italian: Rovere Americano Bianco; German: Stieleiche, Traubeneiche; Spanish: Roble

Origin: Widespread throughout the eastern United States. The group of white oaks includes many species, of which about eight are marketed.


White oak is similar in color and appearance to European oak. The sapwood of American white oak is light-coloured and the heartwood is light to dark brown. White oak has mostly straight grain with more or less pronounced texture (medium to coarse) and longer medullary rays than red oak. White oak therefore has a higher-quality aspect.

Must be dried slowly; tendency to warp; some collapse and internal cracking.

Texture: Coarse
Grain: Fairly straight and regular
Average weight: 769 kg/m3
Shrinkage: Medium to high
Dimensional stability: Strong
Hardness: Medium to high
Compression strength: Average value: 52 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: Average value: 12,600 MPa
Shock resistance: Good
Flexibility: Fair
Durabilità: Good

Botanical name White Beech:
The.

Local designations: Fo, Beech, Fajar, Vespul, Faz, Beech

Denominations other European countries: French: hetre; English: Beech; German: Holes; Spanish: Haya

Provenance:
Beech is present in pure or mixed woodland formations on almost all of Europe, excluding the northernmost strip.


In general and in normal conditions the wood is rosy brown on all the cross section, thus being able to be considered as undifferentiated; Tight and smooth weaving, on tangential surfaces shows a ray grain and a spotted motif on those sheared in quarters.

Pretty good; Drying with care, tends to cracking and distorts, shrinks quickly.

Weaving: very fine
Grain: not always straight
Average Specific Weight: 730 kg/m3
Withdrawal: high
Nervousness: High
Hardness: high
Axial Compression resistance: mean Value 61 MPa
Bending strength: mean Value 118 MPa
Modulus of elasticity: mean Value 14.700 MPa
Impact Resistance: High
Flexibility: medium
Durability: Mediocre

Botanical name Evaporated Beech:
Fraxinus spp.

Denominazioni locali: northern Ash, southern Ash

Denominazioni altri paesi europei: French: Frêne; English: Ash; Italian: Frassino americano; German: Esche; Spanish: Fresno

Origin:
United States


The whitish-yellow sapwood differs from the slightly darker heartwood; a central blackish area occasionally appears, irregular in outline. Large to medium texture, straight grain, pronounced growth rings.

Relatively good, but tends to distort and split at the end of the grain at high temperatures.

Texture: Coarse
Grain: Fairly straight and regular
Average weight: 673 kg/m3
Shrinkage: Medium
Dimensional stability: Medium
Durezza: Medium
Compression strength: Average value: 51 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: Average value:11,997 MPa
Shock resistance: Significant
Flexibility: Fair
Durability: Low to average

Botanical name European Ash:
Fraxinus excelsior L. and Fraxinus Ornus L.

Local designations: Fraissu, Lusa, Fersena, Frosso, Frascinu, Orniello

Denominations other European countries: French: Frene; English: Ash; German: Bait; Spanish: Fresno.
Provenance: In Italy and in Europe (excluding the northern end) present sporadically in the mixed hardwood formations, from the plain to the Middle Mountain.


The sapwood of whitish yellowish color differs from the slightly darker heartwood: sometimes a central blackish zone appears, with irregular boundary (olive ash) presumably caused by fungal attacks. The radial surfaces appear of pearly gloss thanks to the numerous and very fine medullary rays.

The drying process is quite easy, but in its course there can be serious deformation: it is therefore necessary to proceed with prudence and at the end to undergo a good reconditioning to the saats.

Texture: Coarse
Grain: Fairly straight and regular
Average Specific Weight: 720 kg/m3
Shrinkage: Medium
Dimensional stability: Medium
Durezza: Medium
Compression strength: Average value: 51 MPa
Flexural strength: Average value: 106 MPa
Modulus of elasticity: mean Value 12.800 MPa
Shock resistance: Significant
Flexibility: Fair
Durability: Low to average

Botanical name tulipier:
Lirìodendron Tulipifera L.

Local designations: Tulip wood, and, quite improperly given the great diversity of the Tulip Poplar and Yellow Poplar botanical characters.

Other European Countries designations: France: Tulipier; Germany: Tulpenbaum; UK American Whitewood.
Provenance: East Central area of the United States, Great Lakes and the Mississippi Basin to the Atlantic coast, excluding Florida.


The white sapwood, sometimes variegated, is well distinct from the dark brown heartwood and greenish brown tinging sometimes in yellow, porporine, or blackish blue tones.

It dries easily at low temperatures.

Weaving: Medium and regular
Grain: Straight
Average Specific Weight: 447 kg/m3
Shrinkage: Medium to high
Dimensional stability: Medium
Durezza: Medium
Axial Compression resistance: mean Value 37 MPa
Bending strength: mean Value 70 MPa
Modulus of elasticity: mean Value 10.900 MPa
Impact Resistance: Low
Flexibility: Poor
Durability: Poor

Botanical name Hard American Maple:
Acer saccharum, A. nigrum

Local designations: Sugar Maple, black maple

Denominations other European countries: English: Hard Maple (generically)

provenance:
Eastern United States, in particular the States of the Atlantic Center and the Great Lakes region. A cold climate tree that prefers a more northerly environment.


The sapwood is creamy white with a slight reddish brown tinge, while the heartwood varies from pale to dark reddish brown. The amount of darker brown heartwood can vary significantly depending on the region in which the hard maple grows. Both Sapwood and heartwood may contain streaks. The wood has fine and compact veins and generally a straight fibre, but it can also present “feather effect”, “marbling” and “occhiolinate” figures.

Must be slowly dried; tendency to deformation.

Texture: Fine
Grain: Variable, often wavy
Average weight: 705 kg/m3
Shrinkage: Medium to high
Dimensional stability: Medium
Hardness: Medium to high
Axial Compression resistance: mean Value 54 MPa
Bending strength: mean Value 132 MPa
Modulus of elasticity: mean Value 12.618 MPa
Shock resistance: Medium
Flexibility: medium
Durabilità: Good

Botanical name dibetou:
Lovoa Trichiliodes

Local names: African walnut, Bibolo, Lovoa

Names in other European countries: African walnut, Bibolo, Lovoa

Origin:
East and Central Africa.


The sapwood has a modest expanse and a greyish-white colour; it is clearly differentiated from the heartwood that is brown-variegated and sometimes with golden or reddish hues. The interwoven grain produces a nice striped design on surfaces sliced into quarters, and free from knots.

Good; dries rather quickly without too much distortion or cracks; fairly stable

Texture: Moderately fine
Grain: Mostly interwoven
Average weight: 510 kg/m3
Shrinkage: Low to medium
Dimensional stability: Low to medium
Hardness: Relatively low
Compression strength: Average value: 47 MPa
Flexural strength: Average value: 96 MPa
Modulus of elasticity: Average value: 8,600 MPa
Shock resistance: Low to average
Flexibility: High to medium
Durabilità: Good

Botanical name iroko:
Chlorophora excelsa Benth. & Hook. F., C. Regia A. Chev.

Local names: Abang, Kambala, Odum, Intule, Rokko, Moreira

Names in other European countries: Francia, Germania, R.U.: lroko ma, erroneamente, anche Chène d’Afrique, African Teak

provenance:
Equatorial forests of the countries surrounding the Gulf of Guinea: The second mentioned species is present in the eastern area, from Ethiopia to Mozambique


The thick yellowish-white sapwood is clearly differentiated from the heartwood whose primary colour is yellow with golden hues, sometimes tending to brown. Texture rather straight, the interwoven fibres make for a characteristic grain on pieces sliced into quarters. White spots caused by chalky deposits are often present. Good resistance to acid and fire. Iroko is sometimes compared to teak.

Relatively good; minimal deformations and cracks.

Texture: Medium to coarse
Grain: Not always regular
Average weight: 660 kg/m3
Shrinkage: Low
Dimensional stability: Medium
Durezza: Medium
Compression strength: Average value: 55 MPa
Flexural strength: Average value: 116 MPa
Modulus of elasticity: Average value: 10,000 MPa
Shock resistance: Low to average
Flexibility: Medium to high
Durabilità: Good

Botanical name noce canaletto:
Juglans Nigra

Local names: Noce cataletto, black walnut, american walnut

Names in other European countries: French: Noyer; Italian: Noce nazionale; German: Nussbaum; Spanish: Nogal

Origin: Widespread throughout the eastern United States.


The sapwood of walnut is creamy-white while the heartwood is from light to dark chocolate-brown, sometimes with a purplish cast and darker streaks. Walnut can be supplied as natural or evaporative so as to darken the sapwood. The grain is generally straight, sometimes with sinuous or curly forms that produce a variegated and decorative design. The heartwood, dark in colour, tends to lighten over time on exposure to ultraviolet light.

Slow drying improves performance, reducing the possibility of degradation. This wood has good stability.

Texture: Medium to coarse
Grain: Straight to irregular
Average weight: 640 kg/m3
Shrinkage: Medium
Dimensional stability: Low
Durezza: Medium
Compression strength: Average value: 52 MPa
Flexural strength: Average value: 102 MPa
Modulus of elasticity: Average value: 12,000 MPa
Shock resistance: Medium
Flexibility: Poor
Durabilità: Good

Botanical name sapelli:
Entandrophragma Cylindricumarix

Local names: Njeli, Assié, Doetue, Mebrou, Gedu-nohor, Akuk, Abebay, Timbi, Kosi-kosi, Momboyo, Kalungi, Tshimaye, Muyovu, Mavungoti.

Names in other European countries: Sapelli, Sipo, Sapele

Provenienza:
Rainforests and the edges of the savannah on the tropical equatorial belt that runs from Sierra Leone to the Central African Republic and the Congo Basin, with an easterly extension into Uganda


The thin sapwood varies in colour from whitish to pinkish-grey and is clearly differentiated from the reddish-brown or violet heartwood. Contact with metals may cause dark spots. Narrow texture; interwoven grain; stripe pattern on wood sliced into quarters; tangential cuts reveal pronounced growth rings. When recently cut, smells like cedar. When recently cut, smells like cedar.

Should be dried with care; seasoning needed to avoid warping

Texture: Average to fine
Grain: Regularly interwoven
Average weight: 690 kg/m3
Shrinkage: Low to medium
Dimensional stability: Low
Durezza: Medium
Axial Compression resistance: mean Value 61 MPa
Flexural strength: Average value: 145 MPa
Modulus of elasticity: Average value: 11,500 MPa
Impact Resistance: Low
Flexibility: medium
Durabilità: Good
