Window Scantlings
Product Description
The lamellar profile is composed of three or more layers of dried, planed, selected and glued wooden slats. It ensures maximum rigidity combined with high quality and workability.
The use of the glulam profile is the ideal technological solution for all wooden doors and windows, and allows the creation of high-quality manufactured items in a short time, with certainty on costs.
Technical Informations
Size
– Thickness 3 layers: 63 – 72 mm
– Thickness 4 layers: 84 – 96 mm
– Width: 75 – 86 – 95 – 105 – 115 – 125 – 145 mm
– On request it is possible to realize other dimensions
Technological characteristics
– Solid external staves, solid internal lamellas or with two staves glued in width
– Glueing: UNI EN 204 D4
– Humidity: 12% +/- 2%
– Finish: surface planed and clear cutted ends
Wood species available
Botanical name
:
Quercus alba
Local names: White Oak
Names in other European countries: English (generic): Oak; Italian: Rovere Americano Bianco; German: Stieleiche, Traubeneiche; Spanish: Roble
Origin: Widespread throughout the eastern United States. The group of white oaks includes many species, of which about eight are marketed.
White oak is similar in color and appearance to European oak. The sapwood of American white oak is light-coloured and the heartwood is light to dark brown. White oak has mostly straight grain with more or less pronounced texture (medium to coarse) and longer medullary rays than red oak. White oak therefore has a higher-quality aspect.
Must be dried slowly; tendency to warp; some collapse and internal cracking.
– Texture: Coarse
– Grain: Fairly straight and regular
– Average weight: 769 kg/m3
– Shrinkage: Medium to high
– Dimensional stability: Strong
– Hardness: Medium to high
– Compression strength: Average value: 52 MPa
– Flexural strength: Average value: 106 MPa
– Modulus of elasticity: Average value: 12,600 MPa
– Shock resistance: Good
– Flexibility: Fair
– Durabilità: Good
Botanical name:Fraxinus excelsior L. and Fraxinus Ornus L.
Local designations: Fraissu, Lusa, Fersena, Frosso, Frascinu, Orniello
Denominations other European countries: French: Frene; English: Ash; German: Bait; Spanish: Fresno.
Provenance: In Italy and in Europe (excluding the northern end) present sporadically in the mixed hardwood formations, from the plain to the Middle Mountain.
The sapwood of whitish yellowish color differs from the slightly darker heartwood: sometimes a central blackish zone appears, with irregular boundary (olive ash) presumably caused by fungal attacks. The radial surfaces appear of pearly gloss thanks to the numerous and very fine medullary rays.
The drying process is quite easy, but in its course there can be serious deformation: it is therefore necessary to proceed with prudence and at the end to undergo a good reconditioning to the saats.
– Texture: Coarse
– Grain: Fairly straight and regular
– Average Specific Weight: 720 kg/m3
– Shrinkage: Medium
– Dimensional stability: Medium
– Durezza: Medium
– Compression strength: Average value: 51 MPa
– Flexural strength: Average value: 106 MPa
– Modulus of elasticity: mean Value 12.800 MPa
– Shock resistance: Significant
– Flexibility: Fair
– Durability: Low to average
Botanical name
:
Pine
Local designations: Dasa, Salvatico Pine. For the import material the designations are: pine of Sweden or north, Volga Pine, Ponentino.
Other European Countries designations: French: Pin Sylvestre; English: Scotch Pine Redwood; German: Gemeine Kiefer, Fohre; Spanish: Pino Albar.
Provenance: In Italy: Alpine chain and Northern Apennines; In Europe all the central-northern band.
Broad white whitened sapwood, distinctly differentiated from rosy or light reddish brown heartwood, with well-distinct, very resinous, increment rings; Wide texture; Resinous Light accretion rings; Knotty.
Good Dries quickly.
– Texture: Medium
– Grain: Straight
– Average Specific Weight: 550 kg/m3
– Shrinkage: Low to medium
– Nervousness: modest to Medium
– Hardness: Low
– Axial Compression resistance: mean Value 45 MPa
– Bending strength: mean Value 97 MPa
– Modulus of elasticity: mean Value 13.750 MPa
– Impact Resistance: Modest
– Flexibility: medium
– Durability: Modest
Botanical Name:Larix decidua Mi
Local designations: Brenva, Brengula, Lares, Ares, Mersu, Malesu
Denominations other European countries: French: Mélèze; English: Larch; German: Larche; Spanish: Alerce
Provenance: In Italy: Alpine arc.
In Europe present, albeit with discontinuity, in various mountainous areas: related species (e.g. Larix sibirica Ledeb.) They cover important extensions in Russia and Canada
The yellowish sapwood, of modest thickness, is distinctly differentiated from the red heartwood, reddish brown or even porporino; Weaving from wide to narrow; resinous, big difference between spring and late wood; Small knots; Pretty aromatic.
Good Stable when dried.
– Weaving: from end to medium
– Grain: Generally straight
– Average weight: 650 kg/m3
– Shrinkage: Medium
– Dimensional stability: Medium
– Hardness: Low
– Compression strength: Average value: 51 MPa
– Bending strength: mean Value 93 MPa
– Modulus of elasticity: mean Value 14.000 MPa
– Shock resistance: Fair
– Flexibility: Mediocre
– Durability: Durability
Botanical name: Entandrophragma Cylindricumarix
Local names: Njeli, Assié, Doetue, Mebrou, Gedu-nohor, Akuk, Abebay, Timbi, Kosi-kosi, Momboyo, Kalungi, Tshimaye, Muyovu, Mavungoti.
Names in other European countries: Sapelli, Sipo, Sapele
Provenienza: Rainforests and the edges of the savannah on the tropical equatorial belt that runs from Sierra Leone to the Central African Republic and the Congo Basin, with an easterly extension into Uganda
The thin sapwood varies in colour from whitish to pinkish-grey and is clearly differentiated from the reddish-brown or violet heartwood. Contact with metals may cause dark spots. Narrow texture; interwoven grain; stripe pattern on wood sliced into quarters; tangential cuts reveal pronounced growth rings. When recently cut, smells like cedar. When recently cut, smells like cedar.
Should be dried with care; seasoning needed to avoid warping
– Texture: Average to fine
– Grain: Regularly interwoven
– Average weight: 690 kg/m3
– Shrinkage: Low to medium
– Dimensional stability: Low
– Durezza: Medium
– Axial Compression resistance: mean Value 61 MPa
– Flexural strength: Average value: 145 MPa
– Modulus of elasticity: Average value: 11,500 MPa
– Impact Resistance: Low
– Flexibility: medium
– Durabilità: Good
Botanical name
:
Chlorophora excelsa Benth. & Hook. F., C. Regia A. Chev.
Local names: Abang, Kambala, Odum, Intule, Rokko, Moreira
Names in other European countries: Francia, Germania, R.U.: lroko ma, erroneamente, anche Chène d’Afrique, African Teak
provenance: Equatorial forests of the countries surrounding the Gulf of Guinea: The second mentioned species is present in the eastern area, from Ethiopia to Mozambique
The thick yellowish-white sapwood is clearly differentiated from the heartwood whose primary colour is yellow with golden hues, sometimes tending to brown. Texture rather straight, the interwoven fibres make for a characteristic grain on pieces sliced into quarters. White spots caused by chalky deposits are often present. Good resistance to acid and fire. Iroko is sometimes compared to teak.
Relatively good; minimal deformations and cracks.
– Texture: Medium to coarse
– Grain: Not always regular
– Average weight: 660 kg/m3
– Shrinkage: Low
– Dimensional stability: Medium
– Durezza: Medium
– Compression strength: Average value: 55 MPa
– Flexural strength: Average value: 116 MPa
– Modulus of elasticity: Average value: 10,000 MPa
– Shock resistance: Low to average
– Flexibility: Medium to high
– Durabilità: Good
